One technology, two wavelengths, multiple treatments, for all skin types

The power of yellow light for skin health and beauty

An innovative Danish technology with a wide range of medical therapies, with 25 treatments approved by the FDA/CE.

A complete dual-wavelength laser that combines two unique wavelengths: 589 nm, the standard of excellence for treating vascular lesions, and 1319 nm, the benchmark for clinical and aesthetic treatments.

A synergistic combination that creates new treatment paths.

How does the technology work?

Patented PulSync technology

The ADVATx is based on our patented pulse synchronization technology, or PulSync.

It consists of two laser modules, one emitting 1064nm, the other 1319nm, and a modular Q-Switch to generate a train of pulses. These pulses are synchronized and sent simultaneously through an LBO, or non-linear crystal, which combines the wavelengths of the respective 1064nm and 1319nm photons to generate a 589nm, or yellow, light.

Em alternativa, podem ser seleccionados 1319nm, dependendo dos objetivos do tratamento.

Advanced Soft Pulsing energy delivery system (589 nm)

Thanks to Soft Pulsing, energy delivery takes place in a controlled manner, with the duration of the individual pulse and the spacing between pulses significantly shorter than the relaxation time of the vessels.

The result is that the right energy is delivered to the cells within the Thermal Relaxation Time (TRT) of the epidermis, so that the body perceives the pulses delivered as a continuous wave of energy.

This innovation allows for longer pulses without damaging the epidermis and generates photocoagulation rather than cell disruption.
With this, ADVATx delivers all the known therapeutic benefits of yellow light, minimizing discomfort and without the undesirable side effects associated with PDL (Pulsed Dye Laser).

It is important to know that the 1319 nm wavelength is delivered as a continuous wave, allowing controlled and gradual heating of the tissue for optimal fibroblast proliferation and reduction of sebum production from the sebaceous glands.

589 nm effect on the tissue

  • Penetration up to 1mm;
  • Chromophore Oxyhemoglobin and Melanin;
  • Reduces inflammation of the subcutaneous vessels, releasing thrombin into the interstitial space, also producing
  • NeoCollagenesis;
  • Reduces Porphyrin (Qband), reducing the bacterial load;
  • Generates apoptosis of the C-acnes bacteria through a chemical reaction (production of oxygen molecules);

1319 nm effect on the tissue

  • Penetration up to 2mm;
  • Chromophore Water;
  • The increase in temperature in the fibroblasts results in the stimulation of collagen I, III and VII production;
  • It also results in an increase in the thickness and density of the skin, reducing wrinkles and scars;
  • Reduces oiliness by acting on the sebaceous glands;
  • Due to the thermal stimulus, it stimulates the healing response;

Synergistic Effect

Together, the 589 nm + 1319 nm and the Soft Pulsing effect have a synergistic effect that makes it possible to treat both wavelengths in the same session, acting on photocoagulation and photooxidation, without damage to the epidermis or risk to the patient.

Simple and Intuitive Interface

Usability is one of the cornerstones of ADVATx‘s development. The user interface is simple, intuitive and easy to use, which allows it to be a technology with a quick learning curve to operate and possible to delegate.

A Single Handpiece

Single Spot or Fractional scanning, both 589 nm and 1319 nm are delivered via the same handpiece. More speed and convenience during treatment.

Scanning Patterns

The ADVATx scanner offers different scanning patterns, allowing the doctor to adapt the application of laser energy according to the area being treated.

Low Maintenance Costs

The ADVATx is a device that does not require calibration or alignment and does not use consumables. It is easy to transport, as it can be laid flat, and its action is silent as it has no forced ventilation.

  • No flash bulbs or mirror assemblies
  • No toxic dyes
  • No cooling liquids

Beyond Aesthetics

With a high anti-inflammatory power and a super complete spectrum of indications, ADVATx solves skin problems to improve patients’ quality of life, as well as being a powerful tool for rejuvenation treatments.

Vascular lesions, pigments, scars and acne problems, ADVATx is set to become the laser of choice for doctors dedicated to offering their patients the most advanced laser solutions available.

The best patient experience and outcome

ADVATx offers the best treatment experience in a much more comfortable and pain-free way for all phototypes. Results can be seen right after the first session and with minimal recovery time, without disrupting the patient’s routine.

  • Surprising and effective results
  • No skin damage (edema, PIH, crusting, peeling or purpura)
  • No need for anesthesia
  • Quick sessions
  • Maximum application comfort
